SD8530AS

PRIMARY SIDE REGULATOR WITH BUILT-IN HIGH VOLTAGE TRANSISTOR

Description Main feature Product specification classification Internal block diagram Technical documentation Relevant package outline drawing

SD8530AS is primary side regulator (PSR) with built-in high voltage transistor. It provides built-in cable drop compensation and peak current compensation. It adopts PFM technology and provides accurate constant voltage, constant current (CV/CC) control loop for high average efficiency and reliability.

Using SD8530AS for system design, few peripheral components are needed without requiring the Opto-coupler, Y capacitor, secondary control circuit and the loop compensation circuit which reduced the cost.

6W output power is recommended for SD8530AS in range of AC85~264V.

Main feature

Built-in high voltage transistor
Primary side control
Low start-up current
Leading edge blanking
Pulse-Frequency Modulation
Overvoltage protection
Undervoltage lockout
Short circuit protection
Over temperature protection
Open Loop Protection
Cable drop compensation
Peak current compensation
Cycle by cycle current limiting

Ordering Information

Product Name	Package form	Marking	Hazardous Substance Control	Packing Type	Remarks
SD8530AS	SOP-7-225-1.27	SD8530AS	Halogen free	Tube
SD8530ASTR	SOP-7-225-1.27	SD8530AS	Halogen free	Tape & reel

Block Diagram

SD8530AS 英文（PS）.png

Documents

title	Types of	Size (KB)	date	Download the latest English version
SD8530AS		0	2023-08-25	SD8530AS Brief Datasheet

Packages

SOP-7-225-1.27
