SDM50A60FA

600V/50A 3-PHASE FULL-BRIDGE DRIVER (INTELLIGENT POWER MODULE)

Description Main feature Product specification classification Internal block diagram Technical documentation Relevant package outline drawing

SDM50A60FA is a 3-phase brushless DC motor driver with high integration and high reliability for high power inverter driving such as air condition, inverter, and industrial sewing machine. It has embedded six low-loss IGBT and three high-speed half-bridge gate drivers with high voltage.

The under voltage, short circuit and over temperature protections integrated make the circuit work safely in a wide range. The current of each phase can be detected separately because there is one independent negative DC terminal for each phase.

SDM50A60FA adopts high-insulation design, compact package and carries heat easily, which makes it easy to use especially for compact installation applications.

Main feature

Built-in six low-loss 600V/30A IGBT
Built-in high-voltage gate driver
Built-in under voltage, over temperature and over current protections
Built-in bootstrap diode
Compatible with 3.3V, 5V MCU interface, active high
Three independent negative DC terminal for inverter current detection
Alarm signal: for low-side under voltage and short circuit protections
Package in DBC design with low thermal resistance
Insulation level: 2500Vrms/min

Ordering Information

Product Name	Package form	Marking	Hazardous Substance Control	Packing Type	Remarks
SDM50A60FA	DIP-27H	SDM50A60FA	Halogen free	Tube

Block Diagram

SDM50A60FA .png

Documents

title	Types of	Size (KB)	date	Download the latest English version
SDM50A60FA		0	2023-07-20	SDM50A60FA Brief Datasheet
