SDH2136U

THREE-PHASE HALFBRIDGE GATE DRIVER

Description Main feature Product specification classification Internal block diagram Technical documentation Relevant package outline drawing

The SDH2136U is a high voltage,high speed gate driver IC, with three independent high side and low side output channels for 3-phase applications. Built-in dead time avoids the cross conduction of both high side and low side power devices, such as N-Channel MOSFETs and IGBTs. Built-in input filter avoids input noise interference. External enable control is available to terminate all six channel outputs simultaneously. Meanwhile, it integrates under-voltage protection and over-current protection functionality, which terminates channels output when under voltage or over current occurs.

Main feature

High-side floating supply offset voltage:600V
Output current:+0.35A / -0.70A
3.3V / 5V input logic compatible
Dead time control
Undervoltage lockout (UVLO) for VCC&VBS
Overcurrent protection turns off all channels
Enable control
Outputs out of phase with inputs
Three independent half bridge drivers
dV/dt immune

Ordering Information

Product Name	Package form	Marking	Hazardous Substance Control	Packing Type	Remarks
SDH2136U	SOP-28-375-1.27	SDH2136U	Halogen free	Tube
SDH2136UTR	SOP-28-375-1.27	SDH2136U	Halogen free	Tape&Reel

Block Diagram


Documents

title	Types of	Size (KB)	date	Download the latest English version
SDH2136U		0	2020-07-09	SDH2136U Brief Datasheet

Packages

SOP-28-375-1.27
